Name

Order Numbers

Switches CSM

CSM377: 4xRJ45 10/100 Mbit / s, IP30, type S7-300

6GK7 377-1AA00-0AA0

CSM1277: 4xRJ45 10/100 Mbit / s, IP30, type S7-1200

6GK7 277-1AA10-0AA0

Media Conversion

X101-1: 1xRJ45 10/100 Mbit / s + 1xBFOC 100 Mbit / s (multi-mode, up to 3 km), IP30

6GK5 101-1BB00-2AA3

SCALANCE X101

X101-1FL: 1xRJ45 10/100 Mbit / s + 1hBFOC 10 Mbit / s (multi-mode, up to 3 km), IP30

6GK5 101-1BY00-2AA3

X101-1AUI: 1xRJ45 10/100 Mbit / s + 1hAUI 10 Mbit / s (15-pin version SUB-D connector), IP30

6GK5 101-1BX00-2AA3

X101-1LD: 1xRJ45 10/100 Mbit / s + 1hBFOC 100 Mbit / s (odnodomovy, up to 26 km), IP30

6GK5 101-1BC00-2AA3

X101-1POF: 1xRJ45 10/100 Mbit / s + 1 ࠀSC 100 Mbit / s (POF, up to 50 m), IP30

6GK5 101-1BH00-2AA3

Switches

SCALANCE

X005/X100

X005: 5xRJ45 10/100 Mbit / s, IP30

6GK5 005-0BA00-1AA3

X005TS: 5xRJ45 10/100 Mbit / s, IP30, -40 ... +75 0 C, GD - E1 (minimum order 20 pcs.)

6GK5 005-0BA00-1CA3

XB004-1: 4xRJ45 10/100 Mbit / s + 1hSC 100 Mbit / s (multidomovy, up to 3 km), IP20

6GK5 004-1BD00-1AB2

XB004-1LD: 4xRJ45 10/100 Mbit / s + 1hSC 100 Mbit / s (single-mode, up to 26 km), IP20

6GK5 004-1BF00-1AB2

XB005: 5xRJ45 10/100 Mbit / s, IP20

6GK5 005-0BA00-1AB2

XB008: 8xRJ45 10/100 Mbit / s, IP20

6GK5 008-0BA00-1AB2

XB005G: 5xRJ45 10/100/1000 Mbit / s, IP20

6GK5 005-0GA00-1AB2

XB008G: 8xRJ45 10/100/1000 Mbit / s, IP20

6GK5 008-0GA00-1AB2

XB004-1G: 4xRJ45 10/100/1000 Mbit / s + 1hSC 1000 Mbit / s (Multim., up to 750 m), IP20

6GK5 004-1GL00-1AB2

XB004-1LDG: 4xRJ45 10/100/1000 Mbit / s + 1hSC 1000 Mbit / s (odnodom., up to 10 km), IP20

6GK5 004-1GM00-1AB2

X104-2: 4xRJ45 10/100 Mbit / s + 2xBFOC 100 Mbit / s (multi-mode, up to 5 km), IP30

6GK5 104-2BB00-2AA3

X106-1: 6xRJ45 10/100 Mbit / s + 1hBFOC 100 Mbit / s (Multidomovy, up to 5 km), IP30

6GK5 106-1BB00-2AA3

X108: 8xRJ45 10/100 Mbit / s, IP30

6GK5 108-0BA00-2AA3

X108PoE: 8xRJ45 10/100 Mbit / s, IP30

6GK5 108-0PA00-2AA3

X112-2: 12xRJ45 10/100 Mbit / s + 2xBFOC 100 Mbit / s (multi-mode, up to 5 km), IP30

6GK5 112-2BB00-2AA3

X116: 16xRJ45 10/100 Mbit / s, IP30

6GK5 116-0BA00-2AA3

X124: 24xRJ45 10/100 Mbit / s, IP30

6GK5 124-0BA00-2AA3

Switches

SCALANCE

X200 * / X200IRT *

XF200

XF200IRT

X204-2: 4xRJ45 10/100 Mbit / s + 2hBFOC 100 Mbit / s (multi-mode, up to 5 km), IP30, RT

6GK5 204-2BB10-2AA3

X204-2LD: 4xRJ45 10/100 Mbit / s + 2hBFOC 100 Mbit / s (single-mode, up to 26km), IP30, RT

6GK5 204-2BC10-2AA3

X204-2TS: 4xRJ45 10/100 Mbit / s + 2hBFOC 100 Mbit / s (multi-mode, up to 5 km), IP20, RT,

6GK5 204-2BB10-2CA2

-40 ... +70 ? C, = 12 ... 32V, EN50155 for railway

X206-1: 6xRJ45 10/100Mbps + 1hBFOC 100 Mbit / s (multi-mode, up to 5 km), IP30, RT

6GK5 206-1BB10-2AA3

X206-1LD: 6xRJ45 10/100Mbps + 1hBFOC 100 Mbit / s (odnodomovy up to 26km), IP30, RT

6GK5 206-1BC10-2AA3

X208: 8xRJ45 10/100 Mbit / s, IP30, RT

6GK5 208-0BA10-2AA3

X208PRO: 8xM12 10/100 Mbit / s, IP65, RT

6GK5 208-0HA00-2AA6

X200-4P IRT: 4hSC 100 Mbit / s (PCF or POF, up to 100 m), IP30, IRT

6GK5 200-4AH00-2BA3

X201-3P IRT: 1xRJ45 10/100 Mbit / s + 3hSC 100 Mbit / s (PCF or POF, up to 100 m), IP30, IRT

6GK5 201-3BH00-2BA3

X201-3P IRT PRO: 1xRJ45 PRO 10/100 Mbit / s 3 hSC PRO 100 Mbit / s

6GK5 201-3JR00-2BA6

(PCF or POF, up to 100 m), IP65, IRT

X202-2P IRT: 2xRJ45 10/100 Mbit / s + 2hSC 100 Mbit / s (PCF or POF, up to 100 m), IP30, IRT

6GK5 202-2BH00-2BA3

X202-2P IRT PRO: 2xRJ45 PRO 10/100 Mbit / s +2 ࠀSC PRO 100 Mbit / s

6GK5 202-2JR00-2BA6

(PCF or POF, up to 100 m), IP65, IRT

X202-2 IRT: 2xRJ45 10/100 Mbit / s + 2hBFOC 100 Mbit / s (multidom., up to 5 km), IP30, IRT

6GK5 202-2BB00-2BA3

X204 IRT: 4xRJ45 10/100 Mbit / s, IP30, IRT

6GK5 204-0BA00-2BA3

X204RNA: 4xRJ45 10/100 Mbit / s, IP20, PRP

6GK5204-0BA00-2KB2

X204RNA EEC: 4xRJ45 10/100 Mbit / s, IP20, PRP

6GK5204-0BS00-3LA3

X204RNA: 4xRJ45 10/100 Mbit / s, IP20, PRP, for ring topologies HASAR

6GK5204-0BA00-2MB2

X204RNA EEC: 4xRJ45 10/100 Mbit / s, IP20, PRP, for ring topologies HASAR

6GK5204-0BS00-2NA3

X204 IRT PRO: 4xRJ45 PRO 10/100 Mbit / s, IP65, IRT

6GK5 204-0JA00-2BA6

X212-2: 12xRJ45 10/100 Mbit / s + 2hBFOC 100 Mbit / s (multi-mode, up to 5 kg), IP30, RT

6GK5 212-2BB00-2AA3

X212-2LD: 12xRJ45 10/100 Mbit / s + 2hBFOC 100 Mbit / s (single, Mbit / s 26 kg), IP30, RT

6GK5 212-2BC00-2AA3

X216: 16xRJ45 10/100 Mbit / s, IP30, RT

6GK5 216-0BA00-2AA3

X224: 24xRJ45 10/100 Mbit / s, IP30, RT

6GK5 224-0BA00-2AA3

XF204: 4xRJ45 10/100 Mbit / s, IP20, RT

6GK5 204-0BA00-2AF2

XF208: 8xRJ45 10/100 Mbit / s, IP20, RT

6GK5 208-0BA00-2AF2

XF204-2: 4xRJ45 10/100 Mbit / s + 2hBFOC 100 Mbit / s (multi-mode, up to 5 km), IP20, RT

6GK5 204-2BC00-2AF2

XF206-1: 6xRJ45 10/100 Mbit / s + 1hBFOC 100 Mbit / s (multi-mode, up to 5 km), IP20, RT

6GK5 206-1BC00-2AF2

XF204 IRT: 4xRJ45 10/100 Mbit / s, IP20, IRT

6GK5 204-0BA00-2BF2

* For PROFINET CBA requires C-PLUG, ordered separately

Switches

SCALANCE X300

X304-2 FE: 4xRJ45 10/100 Mbit / s + 2hSC 100 Mbit / s (multidom., up to 5 km), IP30, RT

6GK5 304-2BD00-2AA3

X306-1LD FE: 6xRJ45 10/100 Mbit / s + 1hSC 100 Mbit / s (odnodom., up to 26 km), IP30, RT

6GK5 306-1BF00-2AA3

X320-1FE: 20xRJ45 10/100 Mbit / s + 1hSC 100 Mbit / s (multidom., up to 5 km), IP30, RT

6GK5 320-1BD00-2AA3

X320-3LD FE: 20xRJ45 10/100 Mbit / s + 3hSC 100 Mbit / s (odnodom., up to 26 km), IP30, RT

6GK5 320-3BF00-2AA3

X307-3: 7xRJ45 10/100 Mbit / s + 3hSC 1000 Mbit / s (multidom., up to 750 m), IP30, RT

6GK5 307-3BL00-2AA3

X307-3LD: 7xRJ45 10/100 Mbit / s + 3hSC 1000 Mbit / s (odnodom., up to 10 km), IP30, RT

6GK5 307-3BM00-2AA3

X308-2: 8xRJ45 10/100 (1x1000) Mbit / s + 2hSC 1000 Mbit / s (multidom., up to 750 m), IP30, RT

6GK5 308-2FL00-2AA3

X308-2LD: 8xRJ45 10/100 (1x1000) Mbit / s + 2hSC 1000 Mbit / s (odnodom., up to 10 km), IP30, RT

6GK5 308-2FM00-2AA3

X308-2LH: 8xRJ45 10/100 (1x1000) Mbit / s + 2hSC 1000 Mbit / s (odnodom., up to 40 km), IP30, RT

6GK5 308-2FN00-2AA3

X308-2LH +: 8xRJ45 10/100 (1x1000) Mbit / s + 2hSC 1000 Mbit / s (odnodom., up to 70 km), IP30, RT

6GK5 308-2FP00-2AA3

X310: 10xRJ45 10/100 Mbit / s (three ports up to 1000 Mbit / s), IP30

6GK5 310-0FA00-2AA3

X310FE: 10xRJ45 10/100 Mbit / s, IP30

6GK5 310-0BA00-2AA3

X308-2M: 4xRJ45 10/100/1000 Mbit / s, two slots for converting modules, IP30

6GK5 308-2GG00-2AA2

X308-2M PoE: 4 x RJ45 PoE 10/100/1000 Mbit / s, two module slots, IP30

6GK5 308-2QG00-2AA2

X308-2M TS: 4xRJ45 10/100/1000 Mbit / s, two slots for converting modules, IP30

6GK5 308-2GG00-2CA2

Modular switches

19 "

SCALANCE XR300

XR324-12M: 12 slots to be conv. modules, 24VDC, front connection, IP30

6GK5 324-0GG00-1AR2

XR324-12M: 12 slots to be conv. modules, ~ 110-230V, front connection, IP30

6GK5 324-0GG00-3AR2

XR324-12M: 12 slots to be conv. modules, 24VDC, back connection, IP30

6GK5 324-0GG00-1HR2

XR324-12M: 12 slots to be conv. modules, ~ 110-230V, back connection, IP30

6GK5 324-0GG00-3HR2

XR324-4M EEC: 16xRJ45 10/100/1000 Mbit / s, 4th slot Conv. modules, 24VDC, front connection

6GK5 324-4GG00-1ER2

XR324-4M EEC: 16xRJ45 10/100/1000 Mbit / s, 4th slot Conv. modules, 24VDC, back connection

6GK5 324-4GG00-1JR2

XR324-4M EEC: 16xRJ45 10/100/1000 Mbit / s, 4th slot Conv. module = 2h24V, front connection

6GK5 324-4GG00-2ER2

XR324-4M EEC: 16xRJ45 10/100/1000 Mbit / s, 4th slot Conv. module = 2h24V, back connection

6GK5 324-4GG00-2JR2

XR324-4M EEC: 16xRJ45 10/100/1000 Mbit / s, 4th slot Conv. modules, the 60 ~ 250V, front connection

6GK5 324-4GG00-3ER2

XR324-4M EEC: 16xRJ45 10/100/1000 Mbit / c, 4th slot Conv. modules, the 60 ~ 250V, back connection

6GK5 324-4GG00-3JR2

XR324-4M EEC: 16xRJ45 10/100/1000 Mbit / s, 4th slot Conv. modules, ~ 2x60-250V, front connection

6GK5 324-4GG00-4ER2

XR324-4M EEC: 16xRJ45 10/100/1000 Mbit / c, 4th slot Conv. modules ~ 2x60-250V, back connection

6GK5 324-4GG00-4JR2

XR324-4M PoE: 8PoE +8 xRJ45 10/100/1000 Mbit / s, 4th slot Conv. modules, 24VDC, front connection

6GK5 324-4QG00-1AR2

XR324-4M PoE: 8PoE +8 xRJ45 10/100/1000 Mbit / s, 4th slot Conv. modules, 24VDC, back connection?

6GK5 324-4QG00-1HR2

XR324-4M PoE: 8PoE +8 xRJ45 10/100/1000 Mbit / c, 4th slot Conv. modules, ~ 110-230V, front connection

6GK5 324-4QG00-3AR2

XR324-4M PoE: 8PoE +8 xRJ45 10/100/1000 Mbit / c, 4th slot Conv. modules, ~ 110-230V, back connection

6GK5 324-4QG00-3HR2

Converts modules

MM 991-2, 2x 100 Mbit / c, multidomovoy FO up to 5 km, sockets BFOC

6GK5 991-2AB00-8AA0

MM 991-2LD, 2x 100 Mbit / c, odnodomovy FO up to 26 km, sockets BFOC

6GK5 991-2AC00-8AA0

MM 991-2, 2x 100 Mbit / c, multidomovy FO up to 5 km, nests SC

6GK5 991-2AD00-8AA0

MM 991-2LD, 2x 100 Mbit / c, odnodomovy FO to 26 km, SC sockets

6GK5 991-2AF00-8AA0

MM 991-2LH +, 2x 100 Mbit / c, odnodomovy FO to 70 km, SC sockets

6GK5 991-2AE00-8AA0

MM 992-2CUC, 2x RJ45 10/100/1000 Mbit / s, with holder

6GK5 992-2GA00-8AA0

MM 992-2CU, 2x RJ45 10/100/1000 Mbit / c, without support

6GK5 992-2SA00-8AA0

MM 992-2SFP, 2x 100/1000 Mbit / c, SFP slot

6GK5 992-2AS00-8AA0

MM 992-2, 2x 1000 Mbit / c, multidomovy FO to 750 meters, sockets SC

6GK5 992-2AL00-8AA0

MM 992-2LD, 2x 1000 Mbit / s, single-mode FO to 10 km, SC sockets

6GK5 992-2AM00-8AA0

MM 992-2LH, 2x 1000 Mbit / c, odnodomovy FO to 40 km, SC sockets

6GK5 992-2AN00-8AA0

MM 992-2LH +, 2x 1000 Mbit / s, single-mode FO to 70 km, SC sockets

6GK5 992-2AP00-8AA0

MM 992-2ELH, 2x 1000 Mbit / s, single-mode FO 120 km, nests SC

6GK5 992-2AQ00-8AA0

SFP 991-1, 1x 100 Mbit / s, multimode FO to 5 km socket LC

6GK5 991-1AD00-8AA0

SFP 991-1LD, 1x 100 Mbit / s, onomodovy FO up to 26 km, nests LC

6GK5 991-1AF00-8AA0

SFP 991-1LH +, 1x 100 Mbit / s onomodovy FO 70 km socket LC

6GK5 991-1AE00-8AA0

SFP 992-1, 1x 2ࠀ1000 Mbit / s, multimode FO to 750 m, LC socket

6GK5 992-1AL00-8AA0

SFP 992-1LD, 1x 1000 Mbit / s, onomodovy FO to 10 km, nests LC

6GK5 992-1AM00-8AA0

SFP 992-1LH, 1x 1000 Mbit / s, onomodovy FO to 40 km, nests LC

6GK5 992-1AN00-8AA0

SFP 992-1LH +, 1x 1000 Mbit / s, onomodovy FO to 70 km, nests LC

6GK5 992-1AP00-8AA0

SFP 992-1ELH, 1x 1000 Mbit / s, onomodovy FO 120 km, nests LC

6GK5 992-1AQ00-8AA0

X307-2EEC:

power = 24-48V

6GK5 307-2FD00-1EA3

7hRJ45, 10/100

power = 24-48V, specially coated board

6GK5 307-2FD00-1GA3

(2x1000) Mbit / s +

power = 24-48V, redundant power supply circuit

6GK5 307-2FD00-2EA3

2hLC 100 Mbit / s

power = 24-48V, redundant power supply circuit, spec. cover. Boards

6GK5 307-2FD00-2GA3

multidomovy FO

supply ~ 60-250V

6GK5 307-2FD00-3EA3

up to 5 km

supply ~ 60-250V, specially coated board

6GK5 307-2FD00-3GA3

supply ~ 60-250V, redundant power supply circuit

6GK5 307-2FD00-4EA3

Power supply ~ 60-250V, redundant power supply circuit, spec. cover. Boards

6GK5 307-2FD00-4GA3

X302-7EEC:

power = 24-48V

6GK5 302-7GD00-1EA3

2hRJ45,

power = 24-48V, specially coated board

6GK5 302-7GD00-1GA3

10/100/1000 Mbit / s

power = 24-48V, redundant power supply circuit

6GK5 302-7GD00-2EA3

+ 7hLC, 100Mb / s,

power = 24-48V, redundant power supply circuit, spec. cover. Boards

6GK5 302-7GD00-2GA3

multi-mode FO

supply ~ 60-250V

6GK5 302-7GD00-3EA3

up to 5 km

Power supply 60-250V ~, specially coated board

6GK5 302-7GD00-3GA3

Power supply ~ 60-250V, redundant power supply circuit

6GK5 302-7GD00-4EA3

Power supply ~ 60-250V, redundant power supply circuit, spec. cover. Boards

6GK5 302-7GD00-4GA3

Modular Switches

X414-3E: 2x RJ45 10/100/1000 Mbit / s, 12 x RJ45 10/100 Mbit / s;

6GK5 414-3FC00-2AA2

SCALANCE X400

1 slot for MM492; 2 slots for MM491; interface expansion

X408-2: 4hRJ45 10/100/1000 Mbit / s; 4hRJ45 10/100 Mbit / s, 2 slots for MM491i/ili MM492

6GK5 408-2FD00-2AA2

Expansion Module

EM495-8, 8 x 10/100 Mbit / s, RJ45, with two hulls CV490 4x100

6GK5 495-8BA00-8AA2

EM496-4: 4 slots for MM491, with 4 buildings CV490 2x100

6GK5 496-4MA00-8AA2

Converts modules

MM 492-2, 2x 1000BaseSX, multidomovy FO to 750 meters, sockets SC

6GK5 492-2AL00-8AA2

MM 492-2LD, 2x 1000BaseLX, single-mode FO to 10 km, SC sockets

6GK5 492-2AM00-8AA2

MM 492-2LH, 2x 1000BaseLX, single-mode FO to 40 km, SC sockets

6GK5 492-2AN00-8AA2

MM 492-2LH +, 2x 1000BaseLX, single-mode FO to 70 km, SC sockets

6GK5 492-2AP00-8AA2

MM 492-2ELH, 2x 1000BaseLX, single-mode FO 120 km, nests SC

6GK5 492-2AQ00-8AA2

MM 491-2, 2x 100BaseFX, multidomovy FO up to 5 km, sockets BFOC

6GK5 491-2AB00-8AA2

MM 491-2LD, 2x 100BaseFX, single mode FO up to 26 km, sockets BFOC

6GK5 491-2AC00-8AA2

MM 491-2LH +, 2x 100BaseFX, single mode FO to 70 km, SC sockets

6GK5 491-2AE00-8AA2

Modular switches

19 "

SCALANCE

XR500

XR552-6M: up to 6 slots for 4-port modules, front connection

6GK5 528-0AA00-2AR2

XR552-6M: up to 6 slots for 4-port modules, rear connection

6GK5 528-0AA00-2HR2

XR552-12M: up to 12 slots for 4-portable modules, front connection

6GK5 552-0AA00-2HR2

XR552-12M: up to 12 slots for 4-portable modules, rear connection

6GK5 552-0AA00-2AR2

PS598-1: Power Supply 300W Input Voltage 85 ~ 264V, Output voltage 24V DC

6GK5 598-1AA00-3AA0

FAN597-1: the fan for XR552-12M

6GK5 597-1AA00-8AA0

FAN597-2 fan unit for XR552-6M

6GK5 597-2AA00-8AA0

Module converts

992 mM-4CUC, 4x RJ45 10/100/1000 Mbit / s, with collar

6GK5 992-4GA00-8AA0

MM 992-2CU, 2x RJ45 10/100/1000 Mbit / s, collarless

6GK5 992-4SA00-8AA0

MM 992-4, 4x 1000 Mbit / s, multimode FO to 750 meters, sockets SC

6GK5 992-4AL00-8AA0

MM 992-4LD, 4x 1000 Mbit / c, dnomodovy FO to 10 km, SC sockets

6GK5 992-4AM00-8AA0

MM 991-4, 4x 100 Mbit / c, multi-mode FO up to 5 km, the ST

6GK5 991-4AB00-8AA0

MM 991-4LD, 4x 100 Mbit / s, single-mode FO to 26 km, the ST

6GK5 991-4AC00-8AA0

MM 992-4SFP, 4x 100/1000 Mbit / c, SFP slot

6GK5 992-4AS00-8AA0

SFP 993-1, 1x 10 Gb / s multi-mode FO to 300 m, LC socket

6GK5 993-1AT00-8AA0

SFP 993-1LD, 1x 10 Gbit / s, single-mode FO to 10 km, nests LC

6GK5 993-1AU00-8AA0

SFP 993-1LH, 1x 10 Gbit / s, single-mode FO to 40 km, nests LC

6GK5 993-1AV00-8AA0

Modules

Network Security

SCALANCE S *

S602: interworking data protection, DHCP server, Syslog, symbolic IP addresses

6GK5 602-0BA00-2AA3

10/100 Mbit / c

S602: interworking data protection, DHCP server, Syslog, symbolic IP addresses

6GK5 602-0BA10-2AA3

10/100/1000 Mbit / c

S612: protection of up to 32 devices, support for up to 64 VPN connections, 10/100 Mbit / c

6GK5 612-0BA00-2AA3

S612: protection of up to 128 devices, support for up to 128 VPN connections, 10/100/1000 Mbit / c

6GK5 612-0BA10-2AA3

S613: protection of up to 64 devices, support for up to 128 VPN connections

6GK5613-0BA00-2AA3

OFTNET Security Client V4: Software support for secure VPN connections between the PC / PG

6GK1 704-1VW04-0AA0

network segments and PROFINET, secure elements SCALANCE S

SINEMA Server Basic V11

50 devices

6GK1781-1BA01-1AA0

100 devices

6GK1781-1DA01-1AA0

125 devices

6GK1781-1HA01-1AA0

* Module is required C-PLUG, ordered separately

C-PLUG, removable memory module to save the components SIMATIC NET

6GK1 900-0AB00
